| Parameter | Symbol | Min | Type | Max | Unit | Condition |
| Center Wavelength | λ | 895 | 905 | 915 | nm | |
| Spectral Width | Δλ | 5 | - | - | nm | |
| Pulse Power | Po | - | 75 | - | W | |
| Divergence Perpendicular | θ⊥ | 30 | - | - | ° | |
| Divergence Parallel | θ// | 10 | - | - | ° | |
| Light Emitting Area | s | - | 200*10 | - | um2 | |
| Beam Directivity | θ | -1.5 | 0 | 1.5 | ||
| Threshold Current | ITH | - | 1 | - | A | |
| Operating Current | IOP | - | 30 | - | A | 75W |
| Operating Voltage | VOP | - | 24 | - | V | |
| Operating Pulse Width | t | 1 | - | 100 | ns | |
| Repetition Frequency | f | - | 5 | - | kHz | |
| Duty Ratio | D | - | 0.05 | - | % | |
| Wavelength Temperature Coefficient | - | - | 0.28 | - | nm/℃ |
