| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Conditions |
| Optical Wavelength | λp | 1000 | - | 1680 | nm | - |
| Responsivity | Re=1310 | 0.85 | - | - | A/W | φe=100μw, λ=1310nm |
| Re=1550 | 0.9 | - | - | A/W | φe=100μw, λ=1550nm | |
| Forward Voltage | VF | - | 0.5 | 0.6 | V | IF=1mA |
| Saturated Optical Power | Ps | 10 | dBm | VR = 0 V | ||
| Reverse Breakdown Voltage | VBR | 25 | - | - | V | ID=10μA φe=0 |
| Dark Current | ID | - | - | 20 | nA | Tc=+25℃, VR=5V |
| Junction Capacitance | Cj | - | - | 580 | pF | VR =5V,f=1MHz |
