| Parameter | Symbol | Min | Type | Max | Unit | Test Condition |
| Center Wavelength | lc | 1540 | 1550 | 1560 | nm | CW |
| 1300 | 1310 | 1320 | ||||
| Threshold current | Ith | 9 | 15 | mA | CW, 25℃ | |
| 30 | mA | CW, 85℃ | ||||
| Optical Power Options | Po | 7.6 | 8 | mW | CW, Iop=Ith+20mA | |
| Operating voltage | Vop | 1.2 | 1.6 | V | CW, Iop=50mA | |
| Resistance | R | 10 | 15 | Ω | ||
| Monitoring output current | Im | 100 | 1000 | mA | CW, Iop=Ith+20mA | |
| Dark current (PD) | Id | 100 | nA | VRD=5V | ||
| Slope efficiency | SE | 0.38 | W/A | CW, Iop=Ith+20mA | ||
| Spectrum width (-20dB) | △λ | 1 | nm | CW, Iop=Ith+20mA | ||
| Rise and fall time | Tr,Tf | 150 | Ps | Iop=Ith+20mA, 10~90% | ||
| Side-Mode Suppression Ratio | SMSR | 35 | dB | T=-40 to 85℃ | ||
| Temperature Dependence of | △λ/△T | 0.1 | nm/℃ | CW | ||
| Center Wavelength | ||||||
| Capacitance (PD) | C | 10 | 15 | pF | V r=5V, f=1MHz | |
| Focus length | F | 6.4 | 6.6 | 6.8 | mm |
