| Parameter | Symbol | Min | Type | Max | Unit | Notes |
| Reverse Voltage（LD） | Vr(LD) | 2 | V | |||
| Storage Temperature | Tstg | -15 | 85 | ℃ | Ambient Temperature | |
| Operating Temperature | Topr | -10 | 40 | ℃ | Case Temperature | |
| Lead Soldering Temperature/Time | Ts | 260/10 | ℃/S | |||
| Center Wavelength | λc | λ-15 | λ | λ+15 | nm | Po= Pf |
| Optical Output Power | Pf | - | 5 | - | mW | If=55mA |
| Threshold Current | Ith | - | 25 | 40 | mA | |
| Operating Voltage | Vf | - | 2.1 | 2.5 | V | |
| Working Current | If | - | - | 105 | mA |
